Cable suspender with eyelet cable for wall rails

17,2019,20 / piece

Steel cable, crimped with an eyelet and joined to the nut with a domed screw.
The nut can be inserted at any point on the rail from the front. It works as a slide, tightening the screw blocks it in its place.
Compatible with Planex and Pro-30 rails.

Stocked product: Diameter 2.5 mm, Length 4 m

7 × 7 high strength 2300 N/mm² galvanised steel cable. Max load of the cable with eyelet: 68 kg, to be reduced depending on the rail used.
Eyelet in forged steel, stainless-steel screw, zinc plated nut.

Other lengths and diameters are available upon request (Ø 1.5 mm/1.8 mm/2 mm/2.5 mm/3 mm/4 mm/5 mm).
Nuts can be made for non-listed rails.

Quantity : 20 – 99 5%
Quantity : 100-199 10%
Quantity : 200+ 15%
Clear

Description

The weights that can be handled are based on tests conducted by Chassitech on a traction bench in near-real life conditions. They include a wide safety margin, but these are for indicative purposes. The load resistance depends very much on the quality of fastenings both on the object and in the wall.

Additional information

Diameter


Length
